ONE OF THE LARGEST WHOLESALE - DISTRIBUTOR IN THE UNITED STATES OF WALL & WINDOW AIR CONDITIONERS
Multi Zone Mini Splits
OUTDOOR CONDENSER UNITS
CH48MSPH230VO48,000 BTU230 VoltsHEAT PUMP$3775.66
INDOOR UNITS
CH-24MSPH-230V24,000 BTU230 VoltsHEAT PUMP$850.00
INDOOR UNITS
GWH09QC-D3DNAID/I9,000 BTUWall MountHEAT PUMP$241.00
GWH12QC-D3DNAID/I12,000 BTUWall MountHEAT PUMP$275.00
GWH18QC-D3DNAID/I18,000 BTUWall MountHEAT PUMP$340.00
GEH(12)AA-D3DNAIC12,000 BTUMini Floor ConsoleHEAT PUMP$282.09
GEH(18)AA-D3DNAIC18,000 BTUMini Floor ConsoleHEAT PUMP$325.37
OUTDOOR CONDENSER UNITS
MULTI-ZONE
To match with your indoor unit!
GWHD18ND3EO18,000 BTU22HEAT PUMP$1,015.00
GWHD24ND3EO24,000 BTU22HEAT PUMP$1,378.00
GWHD30ND3EO30,000 BTU22HEAT PUMP$1,986.00
GWHD36ND3EO36,000 BTU22HEAT PUMP$2,746.00
GWHD42ND3EO42,000 BTU22HEAT PUMP$2,938.00
OUTDOOR CONDENSER UNITS
Pair with any New Sophia, Olivia, Sophia Ceiling Cassette or Sophia Slim-Duct Coils
"This condenser keeps me so cool in the summer and so warm in the winter time, even when it's -22 degrees outside!"
5 & 7 YEAR WARRANTY • HEATING & COOLING
CH-HP19M-23019,000 BTU230 VoltsHEAT PUMP$2564.00 CH-HP28M-23028,000 BTU230 VoltsHEAT PUMP$3467.00 CH-HPR36M-23036,000 BTU230 VoltsHEAT PUMP$5394.00 CH-HP48M-23048,000 BTU230 VoltsHEAT PUMP$6681.00 CH-HPR55M-23055,000 BTU230 VoltsHEAT PUMP$7586.00| CH-HPR19M-230VO (Ducted) | ||||
| Cooling Capacity | Heating Capacity | SEER2 | EER2 | COP |
| Btu/h | Btu/h | 19 | 12 | 3.66 |
| 19,000(5,200~23,000) | 20,000(6,400~28,000) | |||
| Outdoor Model | CH-HPR19M-230VO | ||
| Power Supply | Rated | V, Ph, Hz | 208-230V, 1Ph, 60Hz |
| Cooling | Rated Capacity (range) | Btu/h | 19,000(5,200~23,000) |
| Heating | |||
| Rated Capacity (range) | Btu/h | 20,000(6,400~28,000) | |
| HSPF4 | 9.3 | ||
| HSPF5 | 7.5 | ||
| Minimum Circuit Ampacity (MCA) | A | 20 | |
| Max. Fuse | A | 25 | |
| Rated current (RLA) | A | 9.5(3.4~10.3) | |
| Compressor | |||
| Model | KTM240D43UKT | ||
| Type | ROTARY | ||
| Brand | GMCC | ||
| RLA | A | 11 | |
| Input | w | 2,045 | |
| Refrigerant oil | oz | VG74 20.9 | |
| Outdoor fan motor | |||
| Qty | 1 | ||
| Input | w | 150 | |
| RLA | A | 1.7 | |
| Outdoor air flow (Max) | CFM | 2,129.41 | |
| Outdoor noise level (Max) | dB(A) | 61 | |
| Outdoor unit | |||
| Dimensions (WxDxH) | in | 37.24x16.14x31.89 | |
| Packing (WxDxH) | in | 42.91x19.69x34.84 | |
| Net/Gross weight | in | 138.23/149.03 | |
| Refrigerant | |||
| Type/Quantity | oz | R410A | |
| Precharge | ft | 25x2 | |
| Additional Charge (liquid pipe) | oz | 91.71 | |
| Design pressure | PSIG | 550/340 | |
| Refrigerant piping | |||
| Liquid side/Gas side | in | 2x1/4" 2x3/8" | |
| Max. length for all indoor units | ft | 131.23 | |
| Max. length for one indoor unit | ft | 82.02 | |
| Max. height difference between indoor and outdoor | ft | 49.21 | |
| Max. height difference between indoor units | ft | 33 | |
| Ambient temperature | |||
| Cooling | F | 5~122 | |
| Heating | F | -22～75 | |
| CH-HPR28M-230VO (Ducted) | ||||
| Cooling Capacity | Heating Capacity | SEER2 | EER2 | COP |
| Btu/h | Btu/h | 20 | 11.7 | 3.52 |
| 28,000(7,600~33,400) | 28,000(4,500~38,500) | |||
| Outdoor Model | CH-HPR28M-230VO | ||
| Power Supply Rated | V, Ph, Hz | 208-230V, 1Ph, 60Hz | |
| Cooling Rated Capacity (range) | Btu/h | 28,000(7,600~33,400) | |
| Heating | |||
| Rated Capacity (range) | Btu/h | 28,000(4,500~38,500) | |
| HSPF4 | 9.5 | ||
| HSPF5 | 7.5 | ||
| Minimum Circuit Ampacity (MCA) | A | 25 | |
| Max. Fuse | A | 40 | |
| Rated current (RLA) | A | 10.9(5.46~16.05) | |
| Compressor | |||
| Model | KTF310D43UMT | ||
| Type | ROTARY | ||
| Brand | GMCC | ||
| RLA | A | 17.5 | |
| Input | w | 2,765 | |
| Refrigerant oil | oz | VG74 33.8 | |
| Outdoor fan motor | |||
| Qty | 1 | ||
| Input | w | 150 | |
| RLA | A | 1 | |
| Outdoor air flow (Max) | CFM | 2,147.06 | |
| Outdoor noise level (Max) | dB(A) | 63 | |
| Outdoor unit | |||
| Dimensions (WxDxH) | in | 37.24x16.14x31.89 | |
| Packing (WxDxH) | in | 42.91x19.69x34.84 | |
| Net/Gross weight | in | 167.99/179.67 | |
| Refrigerant | |||
| Type/Quantity | oz | R410A | |
| Precharge | ft | 25x3 | |
| Additional Charge (liquid pipe) | oz | 134.04 | |
| Design pressure | PSIG | 550/340 | |
| Refrigerant piping | |||
| Liquid side/Gas side | in | 3x1/4" 2x3/8"+1x1/2" | |
| Max. length for all indoor units | ft | 196.85 | |
| Max. length for one indoor unit | ft | 98.42 | |
| Max. height difference between indoor and outdoor | ft | 49.21 | |
| Max. height difference between indoor units | ft | 33 | |
| Ambient temperature | |||
| Cooling | F | 5~122 | |
| Heating | F | -22～75 | |
| CH-HPR36M-230VO (Ducted) | ||||
| Cooling Capacity | Heating Capacity | SEER2 | EER2 | COP |
| Btu/h | Btu/h | 19 | 11.7 | 3.88 |
| 36,000(17,400~44,000) | 37,000(13,300~52,000) | |||
| Outdoor Model | CH-HPR36M-230VO | ||
| Power Supply Rated | V, Ph, Hz | 208-230V, 1Ph, 60Hz | |
| Cooling Rated Capacity (range) | Btu/h | 36,000(17,400~44,000) | |
| Heating | |||
| Rated Capacity (range) | Btu/h | 37,000(13,300~52,000) | |
| HSPF4 | 10 | ||
| HSPF5 | 8.1 | ||
| Minimum Circuit Ampacity (MCA) | A | 40 | |
| Max. Fuse | A | 60 | |
| Rated current (RLA) | A | 14.2(3.7~21.5) | |
| Compressor | |||
| Model | ATQ360D1UMU | ||
| Type | ROTARY | ||
| Brand | GMCC | ||
| RLA | A | 24 | |
| Input | w | 3,040 | |
| Refrigerant oil | oz | VG74 47.3 | |
| Outdoor fan motor | |||
| Qty | 2 | ||
| Input | w | 126 | |
| RLA | A | 2.5 | |
| Outdoor air flow (Max) | CFM | 4,500 | |
| Outdoor noise level (Max) | dB(A) | 60 | |
| Outdoor unit | |||
| Dimensions (WxDxH) | in | 37.48x16.34x52.48 | |
| Packing (WxDxH) | in | 43.11x19.49x58.27 | |
| Net/Gross weight | in | 223.11/253.97 | |
| Refrigerant | |||
| Type/Quantity | oz | R410A | |
| Precharge | ft | 25x4 | |
| Additional Charge (liquid pipe) | oz | 162.26 | |
| Design pressure | PSIG | 550/340 | |
| Refrigerant piping | |||
| Liquid side/Gas side | in | 4x1/4" 2x3/8"+2x1/2" | |
| Max. length for all indoor units | ft | 262.46 | |
| Max. length for one indoor unit | ft | 114.83 | |
| Max. height difference between indoor and outdoor | ft | 49.21 | |
| Max. height difference between indoor units | ft | 33 | |
| Ambient temperature | |||
| Cooling | F | 5~122 | |
| Heating | F | -22～75 | |
| CH-HPR48M-230VO (Ducted) | ||||
| Cooling Capacity | Heating Capacity | SEER2 | EER2 | COP |
| Btu/h | Btu/h | 20.9 | 11.7 | 3.68 |
| 47,000(18,500~51,000) | 49,000(12,000~59,000) | |||
| Outdoor Model | CH-HPR48M-230VO | ||
| Power Supply Rated | V, Ph, Hz | 208-230V, 1Ph, 60Hz | |
| Cooling Rated Capacity (range) | Btu/h | 47,000(18,500~51,000) | |
| Heating | |||
| Rated Capacity (range) | Btu/h | 49,000(12,000~59,000) | |
| HSPF4 | 8.9 | ||
| HSPF5 | 7.4 | ||
| Minimum Circuit Ampacity (MCA) | A | 42 | |
| Max. Fuse | A | 50 | |
| Rated current (RLA) | A | 18.2(5.8~21.2) | |
| Compressor | |||
| Model | EAPQ420D1UMUA | ||
| Type | ROTARY | ||
| Brand | GMCC | ||
| RLA | A | 30 | |
| Input | w | 3,565 | |
| Refrigerant oil | oz | VG74 49.4 | |
| Outdoor fan motor | |||
| Qty | 2 | ||
| Input | w | 126 | |
| RLA | A | 1 | |
| Outdoor air flow (Max) | CFM | 4,500 | |
| Outdoor noise level (Max) | dB(A) | 65 | |
| Outdoor unit | |||
| Dimensions (WxDxH) | in | 37.48x16.34x52.48 | |
| Packing (WxDxH) | in | 43.11x19.49x58.27 | |
| Net/Gross weight | in | 238.32/269.84 | |
| Refrigerant | |||
| Type/Quantity | oz | R410A | |
| Precharge | ft | 25x5 | |
| Additional Charge (liquid pipe) | oz | 162.26 | |
| Design pressure | PSIG | 550/340 | |
| Refrigerant piping | |||
| Liquid side/Gas side | in | 5x1/4" 3x3/8"+2x1/2" | |
| Max. length for all indoor units | ft | 262.46 | |
| Max. length for one indoor unit | ft | 114.83 | |
| Max. height difference between indoor and outdoor | ft | 49.21 | |
| Max. height difference between indoor units | ft | 33 | |
| Ambient temperature | |||
| Cooling | F | 5~122 | |
| Heating | F | -22～75 | |
| CH-HPR55M-230VO (Ducted) | ||||
| Cooling Capacity | Heating Capacity | SEER2 | EER2 | COP |
| Btu/h | Btu/h | 18.8 | 10.5 | 3.1 |
| 55,000(19,400~57,000) | 55,000(15,500~61,500) | |||
| Outdoor Model | CH-HPR55M-230VO | ||
| Power Supply Rated | V, Ph, Hz | 208-230V, 1Ph, 60Hz | |
| Cooling Rated Capacity (range) | Btu/h | 55,000(19,400~57,000) | |
| Heating | |||
| Rated Capacity (range) | Btu/h | 55,000(15,500~61,500) | |
| HSPF4 | 9.3 | ||
| HSPF5 | 7.3 | ||
| Minimum Circuit Ampacity (MCA) | A | 40 | |
| Max. Fuse | A | 60 | |
| Rated current (RLA) | A | 23.5(3.7~27.2) | |
| Compressor | |||
| Model | EAPQ420D1UMUA | ||
| Type | ROTARY | ||
| Brand | GMCC | ||
| RLA | A | 25 | |
| Input | w | 3,565 | |
| Refrigerant oil | oz | VG74 49.4 | |
| Outdoor fan motor | |||
| Qty | 2 | ||
| Input | w | 126 | |
| RLA | A | 2.5 | |
| Outdoor air flow (Max) | CFM | 4,500 | |
| Outdoor noise level (Max) | dB(A) | 61 | |
| Outdoor unit | |||
| Dimensions (WxDxH) | in | 37.48x16.34x52.48 | |
| Packing (WxDxH) | in | 43.11x19.49x58.27 | |
| Net/Gross weight | in | 233.03/265.87 | |
| Refrigerant | |||
| Type/Quantity | oz | R410A | |
| Precharge | ft | 25x5 | |
| Additional Charge (liquid pipe) | oz | 162.26 | |
| Design pressure | PSIG | 550/340 | |
| Refrigerant piping | |||
| Liquid side/Gas side | in | 5x1/4" 3x3/8"+2x1/2" | |
| Max. length for all indoor units | ft | 262.46 | |
| Max. length for one indoor unit | ft | 114.83 | |
| Max. height difference between indoor and outdoor | ft | 49.21 | |
| Max. height difference between indoor units | ft | 33 | |
| Ambient temperature | |||
| Cooling | F | 5~122 | |
| Heating | F | -22～75 | |
